General |
|
|
CPU |
Intel? 11th CoreTM i7-1165G7, i5-1135G7, i3-1115G4 15W default, 12W/28W BIOS optional or Celeron? 6305E CPU, 15W |
|
Memory |
DDR4-3200, 2*SO-DIMM, up to 64 GB |
|
Storage |
1*SATA 3.0 1*M.2 (Key-M, 2280, PCIe x4 NVMe/ SATA, SSD) |
|
Expansion Interface |
1*M.2 (Key-E, 2230, PCIe+USB, Wifi+BT) 1*M.2 (Key-B, 3052, PCIe/ USB 3.0+USB2.0, 4G/5G) |
|
BIOS |
AMI UEFI BIOS |
|
System |
Windows 10, Linux |
|
I/O Interface |
|
|
Ethernet |
2*Intel? 1Gbps PCIe Ethernet Controller, RJ45 |
|
Serial |
3*RS232, 2*RS232/ TTL, 1*RS232/ RS485/ TTL |
|
USB |
6*USB 3.0, 4*USB 2.0 |
|
Audio |
Realtek? 5.1 channel HDA Codec, with MIC/Line-out and Amplifier |
|
GPIO |
8*Programmable GPIO |
|
Display |
|
|
Display Interface |
2*HDMI: max resolution up to 4096*2160@30Hz 1*LVDS/eDP: LVDS, Dual Channel 24 bit, max resolution up to 1920*1200@60Hz eDP, max resolution up to 3840x2160@60Hz |
|
Multiple Display |
Triple |
|
Mechanical & Environment |
|
|
Dimension |
146*105mm |
|
Power Input |
DC 12V |
| Temperature |
Operation: 0℃~60℃, Storage: -25℃~75℃ |
|
Relative Humidity |
Operation: 10%~90%, Storage: 5%~95%, non-condensing |
