General |
|
|
CPU |
Intel? 8th and 9th Generation CoreTM i3/i5/i7/i9, Pentium?, Celeron? CPU, LGA1151 |
|
Chipset |
Intel? Q370 Chipset, TDP 6W |
|
Memory |
DDR4-2400/2666, 4*U-DIMM, up to 64 GB |
|
Storage |
4*SATA 3.0 1*M.2 (Key-M, 2242/2280, PCIe x4 NVMe/ SATA SSD) |
|
Expansion Interface |
2*PCIe x16 Slot (1*PCIe x16 Gen3 or 2*PCIe x8 Gen3) 1*Mini-PCIe (Wifi/3G/4G Supported) |
|
BIOS |
AMI UEFI BIOS |
|
System |
Windows10, Linux |
|
I/O Interface |
|
|
Ethernet |
1*Intel? Ethernet Controller I219V, RJ45 1*Intel? Ethernet Controller I225V, RJ45 |
|
Serial |
4*RS232,1*RS232/RS485/RS422, 1*RS232/RS485 |
|
USB |
6*USB 3.0, 7*USB 2.0 |
|
Audio |
Realtek? ALC897 5.1 channel HDA Codec, with MIC/Line-out/Line-in |
|
PS/2 |
1*PS/2 Port (Keyboard & Mouse) |
|
GPIO |
8*Programmable GPIO |
|
Display |
|
|
Display Interface |
1*DVI-D: max resolution up to 1920*1200@60Hz
1*HDMI 1.4b: max resolution up to 4096*2160@24Hz
1*VGA: max resolution up to 1920*1200@60Hz |
|
Multiple Display |
Triple |
|
Mechanical & Environment |
|
|
Dimension |
305*244mm |
|
Power Input |
ATX PSU |
| Temperature |
Operation: 0℃~60℃, Storage: -25℃~75℃ |
|
Relative Humidity |
Operation: 10%~90%, Storage: 5%~95%, non-condensing |
